托盘已成为现代物流系统不可缺少的重要器具,为世界各国普遍采用。随着国民经济的发展,特别是我国加入WTO,货物运输不断增加,对模压托盘的需求也在不断增长。过去一直以来,托盘多数以实木作为原材料,以满足托盘市场的需求。但随森林资源的日益减少,充分利用小径级木材、木材加工剩余物以及木质纤维材料就越来越被加以重视,德国、美国相继研究并开发出木质模压刨花托盘,以提高木材及木质纤维材料的利用率。
Pallet has become an indispensable and important instrument in modern logistics system, which is widely used all over the world. With the development of national economy, especially China's accession to the WTO, the freight transportation is increasing, and the demand for molded pallets is also growing. In the past, most pallets used solid wood as raw materials to meet the needs of the pallet market. However, with the decrease of forest resources, more and more attention has been paid to making full use of small-diameter wood, wood processing residues and wood fiber materials. In order to improve the utilization rate of wood and wood fiber materials, wood molded particleboard trays have been developed in Germany and the United States one after another.
模压工业托盘是刨花模压制品中重要的一类,主要用于码头、货场、仓库、车间、等地搬运、贮存货物,它与货物形成一个移动单元或搬运单元,与叉车、搬运车、起重机等配合作用。工业托盘一般规格为400 mm ~600 mm,600mm~800mm, 800mm~1000mm,1000mm~1200mm,1100mm~1100mm。动态承载能力从250kg~1500kg,托盘自重10kg~20kg,托盘的弧形边缘、槽形梁和巧妙的的加强筋设计,使得载重系数高达80(动载)。刨花模压工业托盘为异形,等强度薄壳构件,自重轻,强度大,其承载量与自重比(载重量)高达60~80(动载)和200~300(静载)
Moulded industrial pallet is an important kind of particlemolded products. It is mainly used for handling and storing goods in docks, freight yards, warehouses, workshops, shopping malls and other places. It forms a moving unit or handling unit with the goods and cooperates with forklifts, trucks, cranes and so on. The general specifications of industrial pallets are 400 mm ~ 600 mm, 600 mm ~ 800 mm, 800 mm ~ 1000 mm, 1000 mm ~ 1200 mm and 1100 mm ~ 1100 mm. The dynamic bearing capacity ranges from 250kg to 1500kg, and the dead weight of the pallet ranges from 10kg to 20kg. The arc-shaped edge of the pallet, the trough beam and the ingenious and perfect stiffener design make the load factor as high as 80 (dynamic load). The particlemolded industrial pallet is a special-shaped, equal strength thin shell component with light weight and high strength. Its load-bearing capacity to weight ratio (load) is as high as 60 ~ 80 (dynamic load) and 200 ~ 300 (static load)
模压托盘
presswood pallet
1.分类
1. Classification
创花模压托盘按其结构可分为深腿和浅腿、双面和单面;按装卸方式可分为叉运和吊装两类。
According to its structure, the tray can be divided into deep leg and shallow leg, double side and single side; According to the loading and unloading methods, it can be divided into fork transportation and hoisting.
2.规格
2. Specifications
根据创花模压托盘承重量的不同 ,平板部分厚度一般为8 mm、9 mm支, 腿有4 个、6 个、9 个。支腿可为圆形、方形、长方形,有一定锥度,中空, 壁厚一般为 10 mm左右。产品已规格化系列化。
According to the weight of the tray, the thickness of the plate is generally 8 mm and 9 mm, and there are 4, 6 and 9 legs. Legs can be round, square, rectangular, with a certain taper, hollow, wall thickness is generally about 10 mm. The products have been standardized and serialized.
创花模压托盘的优点是:自重轻,强度高,尺寸精确,形状稳定,无 金属连接件,不会损坏货物或包装;根据使用要求选用不同胶粘剂和添加剂,可得到耐水、阻燃、防腐,一次性使用或重复使用等不同性能的托盘。
The advantages of the tray are: light weight, high strength, accurate size, stable shape, no metal connector, no damage to goods or packaging; According to the requirements of using different adhesives and additives, we can get water-resistant, flame-retardant, anti-corrosion, disposable or reusable pallets.
